Features

• Dual flush (4.5/3L)
• Water entry: Top left rear entry or right/left pan side entry
• P-trap set out height: 185mm
• S-trap set out: Standard: 90mm - 140mm (with vario pan connector & 20mm offset pan collar - supplied).
  Optional: 160mm - 230mm (with long adjustable vario pan connector, 98451A-0 - not supplied)
• Box rim
• Vitreous china

Included Components

• Kohler Dual toilet pan - 21669A-SST-0
• Kohler Dual cistern 4.5L/3L - 76993A-0
• Kohler Dual quiet close, vertical Quick Release toilet wrap seat - 75200A-0
• Vario pan connector
• Offset pan collar (20mm)
• Fill valve for rear entry
• Fill valve for pan side entry (supplied with pan)
• Rear entry water supply hose (pan side entry water supply hose not supplied)
• 2 x caps for pan side entry holes
• 1 x hose ring for pan side entry hole (for use with pan side entry setup only)
• Floor fixing bolts and anchors

  Specification sheet
  Installation instructions
